Name: Road Centerlines

Display Field: FULLNAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Why this layer exists: This layer was created to be used with the cartographic highways layer in the basemap. It was created with Netcurr road segments dissolved based on street name and physical jurisdiction, with manual additions and review. Roads were further split by maintenance responsibility (City Maintained or Not City Maintained) based on Street Maintenance's "Street Conditions" layer. Functional Class (field name DISPDET) was added based on "Functional Classification System HPMS 2026" layer acquired from NMDOT's open data hub. The display class generally matches the functional class but some segments have had their numbers modified for cartographic purposes. Speed limit data is intended to be added after the 2026 RAS collection.Symbolization Notes: This layer is intended to be symbolized based on the Display Class field with increments of roughly 0.4 with 3 being the thickest and 7 being the thinnest. Residential roads (class 7) should only label when zoomed in past 1:10,000. When using this layer with the Cartographic Highways layer use definition query "DISPDET IS NULL Or DISPDET NOT IN ('HIGHWAY', 'INTERSTATE', 'Ramp')"What this layer is used for: This layer is used in the basemap, the Road Maintenance Lookup app, and the NTMP Survey.What this layer is NOT for: This layer is not suitable for routing and contains no addressing information.

Service Item Id: 08d79eb19ba54ec89453373797ab44be

Copyright Text: DMD GIS, NMDOT, AGIS

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1354851.6818890795
YMin: 1405011.8746200725
XMax: 1669066.4993243292
YMax: 1570451.2075049803
Spatial Reference: 2903  (2903)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: DISPLAYCLASS
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1
  Label: Highway/Interstate
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 1
• Value: 0
  Label: Frontage/Ramps
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [178, 178, 178, 255]
  Width: 0
• Value: 3
  Label: Principal Arterial
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 0
• Value: 4
  Label: Minor Arterial
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 0
• Value: 5
  Label: Major Collector
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [104, 104, 104, 255]
  Width: 0
• Value: 6
  Label: Minor Collector
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 0
• Value: 7
  Label: Residential
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [156, 156, 156, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [52, 52, 52, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Segoe UI Semibold
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [78, 78, 78, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Segoe UI Semibold
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 75000.0
Max. Scale: 50000.0
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [104, 104, 104, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 9
Font Family: Segoe UI
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 10000.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• DISPLAYCLASS ( type: esriFieldTypeInteger, alias: Display Class )
• FULLNAME ( type: esriFieldTypeString, alias: Full Street Name, length: 500 )
• CORENAME ( type: esriFieldTypeString, alias: Core Street Name, length: 255 )
• COMMENTS ( type: esriFieldTypeString, alias: Maintainer, length: 500 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• MAINTENANCE ( type: esriFieldTypeString, alias: Maintenance, length: 255 )
• DISPDET ( type: esriFieldTypeString, alias: Functional Class, length: 255 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
