Name: Proposed Bikeway Facilities

Display Field: street_name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This layer displays proposed bikeway facilities identified in the 2024 Bikeway and Facilities Plan (BTFP). Proposals include both the addition of new facilities where none currently exist and modifications to existing infrastructure — such as restriping, roadway speed reductions, and similar improvements — aimed at increasing rider comfort and confidence. All facilities in this layer are on-street or within the public right-of-way; unpaved hiking and open space trails are not included and can be found in data maintained by the Parks Department in the COA database. The plan covers the greater Albuquerque metro area, including facilities proposed within other jurisdictions such as Los Ranchos. The layer is maintained by DMD's Transportation Planning Manager, who removes segments as construction or implementation is completed.Data Dictionary:Facility Type: the type of infrastructure proposed for the project.Street Name: the name of the street on which the infrastructure is proposed.Project Name: The common name used to identify the project. This is often the same as the street name.Strategy: The strategy proposed by the 2024 Bikeways and Trails Facilities Plan (BTFP) for implementing projects such as restriping, future roadway buildout, or curbline modifications.Project Time Frame: Indicates whether the project is Long-Term or Short-Term, as defined in the BTFP.Project ID: a unique number assigned in the BTFP to identify this project.Display: A binary (0/1) field used by BHI, the BTFP consultant, in the creation and presentation of the BTFP data. The field is not currently in use but may be useful in the future for quickly hiding projects from various views.Along HFIN: A binary (0/1) field indicating whether the project is planned along a roadway segment identified as part of the High Fatal & Injury Network (HFIN). A value of 1 indicates that it is. This field will need to be updated following completion of the 2026 HFIN Network.Dual Carriageway: A binary field indicating whether the project is planned along a dual carriageway. A value of 1 indicated that it isNetwork Spine: A binary (0/1) field indicating whether the project is planned along a roadway segment identified by the BTFP as part of the Network Spine. A value of 1 indicates that it is.One Way: A binary (0/1) field indicating whether the project is located on a one-way roadway. A value of 1 indicates that it is.Speed Reduction: A binary (0/1) field indicating whether a speed limit reduction is recommended as part of the proposed project. A value of 1 indicates that a reduction is recommended.Mileage: The length of the proposed infrastructure, measured in miles.Symbology Notes:The planned segments are displayed with a dotted line. The colors used in the BTFP are based on the facility type:Bike Boulevard - 851c9fBuffered Bike Lane - 5555f0Enhanced Bike Route - fb9164Paved Multi-Use Trail & Crossings - 48ac78Separated Bike Lane - 000000Sidepath - 7c963dStandard Bike Lane - 3fbdea

Service Item Id: d7302a499119402a89497014e7c9971b

Copyright Text: BHI, DMD GIS

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1479688.688448161
YMin: 1436212.0185844898
XMax: 1573330.519864913
YMax: 1534777.5051801577
Spatial Reference: 2903  (2903)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: facility
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Bike Boulevard
  Label: Bike Boulevard
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [133, 21, 163, 255]
  Width: 1
• Value: Bike Lane
  Label: Bike Lane
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [53, 190, 238, 255]
  Width: 1
• Value: Buffered Bike Lane
  Label: Buffered Bike Lane
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [85, 85, 247, 255]
  Width: 1
• Value: Enhanced Bike Route
  Label: Enhanced Bike Route
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [253, 143, 93, 255]
  Width: 1
• Value: Paved Multi-Use Trail
  Label: Paved Multi-Use Trail
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [66, 173, 116, 255]
  Width: 1
• Value: Paved Multi-Use Trail Crossing
  Label: Paved Multi-Use Trail Crossing
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [66, 173, 116, 255]
  Width: 1
• Value: Separated Bike Lane
  Label: Separated Bike Lane
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [0, 0, 0, 255]
  Width: 1
• Value: Sidepath
  Label: Sidepath
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [123, 150, 46, 255]
  Width: 1
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• facility ( type: esriFieldTypeString, alias: Facility Type, length: 255 , Coded Values: [Sidepath: Sidepath] , [Enhanced Bike Route: Enhanced Bike Route] , [Bike Boulevard: Bike Boulevard] , ...5 more... )
• street_name ( type: esriFieldTypeString, alias: Street Name, length: 255 )
• project_name ( type: esriFieldTypeString, alias: Project Name, length: 200 )
• strategy ( type: esriFieldTypeString, alias: Strategy, length: 100 )
• timeframe ( type: esriFieldTypeString, alias: Project Time Frame, length: 255 )
• project_uid ( type: esriFieldTypeInteger, alias: Project ID )
• display ( type: esriFieldTypeSmallInteger, alias: Display )
• along_hfin ( type: esriFieldTypeSmallInteger, alias: Along HFIN )
• dual_carriageway ( type: esriFieldTypeSmallInteger, alias: Dual Carriageway )
• spine ( type: esriFieldTypeSmallInteger, alias: Network Spine )
• one_way ( type: esriFieldTypeSmallInteger, alias: One Way )
• speed_reduction ( type: esriFieldTypeSmallInteger, alias: Speed Reduction )
• mileage ( type: esriFieldTypeDouble, alias: Mileage )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
