Name: DMD.SurveyMonuments

Display Field: MONUMENTID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This data contains information on the location and condition of survey monuments within or in the immediate vicinity of the City of Albuquerque. Both vertical and horizontal survey data are kept within the dataset, as well as destroyed or inactive monuments. Monuments are tracked by the survey staff and their condition is updated as staff reviews in-field monuments.

Service Item Id: f967096994bd4ec78e21a4491fbd7541

Copyright Text: City of Albuquerque, Department of Municipal Development; Survey Group

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1411867.8690375797
YMin: 687977.5356664732
XMax: 1702366.9501117505
YMax: 1555155.0461179093
Spatial Reference: 2903  (2903)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: N/A
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Destroyed
  Label: Destroyed
  Description: N/A
  Symbol:

• Value: Horizontal
  Label: Horizontal
  Description: N/A
  Symbol:

• Value: Inactive
  Label: Inactive
  Description: N/A
  Symbol:

• Value: Vertical
  Label: Vertical
  Description: N/A
  Symbol:

• Value: Vertical and Horizontal
  Label: Vertical and Horizontal
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• MONUMENTID ( type: esriFieldTypeString, alias: Monument ID, length: 32 )
• MONUMENTSTATUS ( type: esriFieldTypeString, alias: Monument Status, length: 11 )
• MONUMENT_TYPE ( type: esriFieldTypeString, alias: Monument Type, length: 50 , Coded Values: [Vertical: Vertical] , [Horizontal: Horizontal] , [Vertical and Horizontal: Vertical and Horizontal] )
• ZONE ( type: esriFieldTypeString, alias: Map Zone, length: 8 )
• DateMadeActive ( type: esriFieldTypeDate, alias: DateMadeActive, length: 8 )
• DateMadeInActive ( type: esriFieldTypeDate, alias: DateMadeInActive, length: 8 )
• NAD83LAT_DEG ( type: esriFieldTypeSmallInteger, alias: NAD83 Lat Degree )
• NAD83LAT_MIN ( type: esriFieldTypeSmallInteger, alias: NAD83 Lat Minute )
• NAD83LAT_SEC ( type: esriFieldTypeDouble, alias: NAD83 Lat Second )
• NAD83LON_DEG ( type: esriFieldTypeSmallInteger, alias: NAD83 Long Degree )
• NAD83LON_MIN ( type: esriFieldTypeSmallInteger, alias: NAD83 Long Minute )
• NAD83LON_SEC ( type: esriFieldTypeDouble, alias: NAD83 Long Second )
• ELIPHEIGHTMTR ( type: esriFieldTypeDouble, alias: Ellipsoidal Height in Meters )
• NAD83ORDER ( type: esriFieldTypeSmallInteger, alias: NAD83 Order )
• NAD83CLASS ( type: esriFieldTypeSmallInteger, alias: NAD83 Class )
• NAD83_NORTH_USFT ( type: esriFieldTypeDouble, alias: NAD83 North US ft )
• NAD83_EAST_USFT ( type: esriFieldTypeDouble, alias: NAD83 East US ft )
• NAD83_NORTH_MTR ( type: esriFieldTypeDouble, alias: NAD83 North Meters )
• NAD83_EAST_MTR ( type: esriFieldTypeDouble, alias: NAD83 East Meters )
• MAPPINGANGLE ( type: esriFieldTypeString, alias: Mapping Angle, length: 11 )
• GRS80GEOIDSEPMTR ( type: esriFieldTypeDouble, alias: GRS80 Geoid Seperation Meter )
• NAD83SOURCEDATAFILE ( type: esriFieldTypeString, alias: NAD83 Source Data File, length: 255 )
• NAD83DATELOADED ( type: esriFieldTypeDate, alias: NAD83 Date Loaded, length: 8 )
• NAVD88ORTHOHGHT_USFT ( type: esriFieldTypeDouble, alias: NAVD88 Ortho Height USFT )
• NAVD88ORDER ( type: esriFieldTypeSmallInteger, alias: NAVD88 Order , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...6 more... )
• NAVD88CLASS ( type: esriFieldTypeSmallInteger, alias: NAVD88 Class , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...1 more... )
• NAVD88SOURCEDATAFILE ( type: esriFieldTypeString, alias: NAVD88 Source Data file, length: 255 )
• NAVD88DATELOADED ( type: esriFieldTypeDate, alias: NAVD88 Date Loaded, length: 8 )
• FILELINKDRIVE ( type: esriFieldTypeString, alias: File Link Drive, length: 255 )
• FILELINKOBSTRUCTDIAG ( type: esriFieldTypeString, alias: File Link Obstruct Diagram, length: 255 )
• FILELINKDRAWINGFILE ( type: esriFieldTypeString, alias: File Link Drawing File, length: 255 )
• Note ( type: esriFieldTypeString, alias: Note, length: 255 )
• DATASHEETLINK ( type: esriFieldTypeString, alias: Data Sheet Link, length: 255 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Description_from_Export ( type: esriFieldTypeString, alias: Description_from_Export, length: 1073741822 )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 500 )
• Technician_last_checked ( type: esriFieldTypeString, alias: Technician_last_checked, length: 255 )
• GRND_TO_GRID_FACTOR ( type: esriFieldTypeDouble, alias: Ground to Grid Factor )
• GRNDTOGRIDFACTOR ( type: esriFieldTypeDouble, alias: Ground to Grid Scale Factor )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
